Automatic Anti Corrosive Piston Filling Machine

  • MODEL: HYPF-1000SA
  • Nozzles No.: 1-20pcs customized
Technical Description

Automatic Anti Corrosive Piston Filling Machine is for viscous corrosive liquid and cream with different bottle or jars. Through PLC, and servo motor, Automatic Anti Corrosive Piston Filling Machine can be changed to fill different volume on touch screen. No bottle no filling. It can be used for acidic toilet bowl cleaner.

Main Technical Data
  • Filling range: 50-1000ml
  • Diameter of bottle: Φ40mm~Φ90mm
  • Height of bottle: 80mm-230mm
  • Filling accuracy: +1%(≤200ml)  +0.5%(200-1000ml)
  • Output: ≤3500BPH
  • Air resource: 0.6-0.8MPa
  • Air consumption: 200L/h
  • Power: 2.0KW/AC220V/380V/50Hz/60Hz Customized
  • Weight: 600kg
  • Size(LxWxH): 2000x1050x2300mm

Automatic Anti Corrosive Piston Filling Machine Pictures

Inline Anti Corrosive Piston Filling Machine is suitable for below bottle samples

Click here to view Automatic Inline Piston Filling Machine running video on YouTube
