Professionally produce filling machines and packing machines

HengYuan Machinery Co., Ltd.

Automatic Rotary Multi Heads Capping Machine

  • MODEL: HYRS-S
  • Capping Head No.: 4,6,8pc
  • Working Method: Cap Unscrambling Get and Screw Cap
BASIC INFO
Technical Description

Automatic rotary type grasping-cap capping machine automatic is integrated bottle collecting, cap arranging, cap putting on, cap rotary and bottle exiting in one machine. It uses catching cap positioning rotary cap, whole machine is rotary structure. In the process of rotary cap without injury bottle and cap phenomenon, high efficiency, high qualified rate, stable operation, wide application range. The machine is adaptable for various kinds of outer cap automatic revolve to close for regular glass or plastic bottle, the capping device grasping various caps  transmitted by scraping plate, complete outer cap revolve to close in the bottle rotary process. The machine adopts PLC control, touch human-machine interface, convenient and intuitive operation.
It is widely used in pharmaceutical, chemical, food, beverage, oil and pesticides industries.


Main Technical Data
  • Capping head: 4, 6, 8
  • Maximum capacity: 4500, 6000, 8000B/H
  • Suitable bottle diameter: φ40-90mm
  • Suitable bottle height: 80-250 mm
  • Applicable cap diameter: φ15-φ55 mm
  • Applicable cap height: 15-35mm
  • Percent of pass: ≥99.8%
  • Total Power: 4.5Kw
  • Power supply: 220V, 50Hz
  • Air supply: 0.6-0.8Mpa
  • Dimension: 3500x1380x2100mm
  • Weight: 1500 kg

Automatic Rotary Type Grasping-cap Capping Machine Pictures









Automatic Rotary High Speed Multihead
 Capping Machine is suitable for below bottle samples

high speed pesticide bottle capping machine, rotary high speed shampoo bottle capping machine, automatic rotary hair conditioner multihead capping machine, high speed facial lotion bottle capping machine, rotary edible oil bottle capping machine, high speed honey bottle capping machine, tomato sauce bottle capping machine, single head milk bottle capping machine, single head juice bottle capping machine, high speed jam capping machine, high speed plastic lid capping machine, automatic rotary capping machine, automatic high speed capping machine.



Click here to view Automatic Rotary High Speed Multihead Capping Machine running video on YouTube

https://youtu.be/BY4kKKc64AQ
