Desktop Semi-automatic 360 Degree Turnover Sticker Label Applicator

  • MODEL: HYT-20150
  • Suitable bottle shape: Flat, Square, Round, Polygonal Bottles
  • Stick label quantity: 1,2,3
BASIC INFO
Labeling Machine Introduction
Semi-automatic 360 degree flip non-dry self-adhesive sticker labeling machine can stick non-dry sticker label on a wide shape of bottles, containers and commodities by changing tools. For example: round bottle, cans, jars, container, objects, cone shaped bottles, commodities, flat bottles, four sides and six sides bottles, etc. With inspection of sensor, tracking label synchronously, ensure to labeling speed and smoothly.
Host design labeling machines using imported and domestic advanced technology to improve and make a solution for instability of general domestic labeling. By optical fiber computer control, we can get the synchronization track. The output of labels is controlled by a stepper motor or servo motor. It can detect the objects and size of labels automatically. It is modern and advanced electronic mechanical integration equipment automatically controlled by microcomputer mode, with large LCD touch panel, display and memory devices containing dozens of memory devices. The operation is simple, the labeling is accurate, the performance is reliable, and there is only low noise. Sticker labeling machine is easy to clean, not moldy, beautiful after labeling and of high production efficiency. It is strong and won't fall off on its own.
Semi-automatic sticker labeling application machine is suitable for labeling on objects with different shapes with one, two, three, etc labels.
Automatic 360° turnover type label applicator is widely used in  bottling of daily chemical, agricultural chemical, food, personal care and pharmaceutics industry.

Operation process

*Manual operation:
put bottle to the machine→press foot switch→press top mechanism go down, press the bottle→come out a label→labeling→standard labeled→press top mechanism go up→take out the bottle

*Automatic operation:
put bottle to the machine→test object electric eyes detect has a bottle in place→press top mechanism go down, press the bottle→come out a label→labeling→standard labeled→press top mechanism go up→take out the bottle

Main technical data
  • Labeling capacity: 0~30pcs/min
  • Labeling accuracy: ±0.5 mm
  • Label material: Adhesive sticker, opaque or transparent label
  • The inner diameter of label roll: 76 mm
  • The outer diameter of label roll: 240 mm(max)
  • The suitable size of label: Width 20-150 mm, length 20-300 mm
  • The suitable size of labeling objects: D 12mm~250mm,  length 30mm~250mm,  Can be customized
  • Total Power: 660w
  • Power supply: AC220V/110V, Single phase. Globally customized
  • Net weight: About 60kg
  • Machine size: 83(L)x72(W)x95(H)cm



Semi-automatic 360 Degree Multi-functional Sticker Labeling Machine Picture

Semi-automatic 360 degreen turnover sticker label applicator
semi-automatic 360° turnover sticker labeling machine
Desktop semi-automatic multi-functional label application machine

semi-automatic desktop labeling machinery
semi-automatic cone bottle labeling machine


Semi-auomatic 360 degree turnover multi-functional sticker label applicator details

Semi-automatic hexagon bottle labeling machine

semi-automatic flat botte wrapping labeling machine



Application

  • Applicable Label: sticker label, label roll
  • Applicable products: For all kinds of round,square and irregular shaped objects wrap around labeling by changing mold.
  • Industry: Widely used in food, medicine, wine, and other industries.
  • Application examples: Shampoo bottle labeling machine, hair conditioner bottle labeling machine, wine bottle labeling machine, honey jar labeling machine, ketchup bottle labeling machine, sauce jar labeling machine, tin can labeling machine, pet juice bottle label applicator, medicine bottle labeling machine, tablets bottle label applicator, oral liquid bottle label applicator, etc.
Semi-atuomatic cone jar labeling machinery


Click here to view Semi-automatic 360 Degree Turnover Sticker Labeling Applicator Machine Running Video on YouTube

1. Double-sided sticker labeling
https://youtu.be/bIrjdAAYkMg




2. Cone bottle sticker label application
https://youtu.be/U-_DBazdagQ
