Rotary Gravity filling machine Technical Description
Automatic High Speed Rotary Gravity Flowing Type Bottle Liquid filling machine adopts rotating filling machine technology in our country. It i a high-tech filling equipment controlled by microcomputer PLC programmable, equip with photo electricity transduction and pneumatic action as a whole.Characteristic are: Fast filling speed, accurate measure,non-foam,non-drop.This machine with compact structure,simple transmission,convenient maintain,long service life,beautiful appearance.The product extensive used for non-aerated beverage,fruit juice,soy,vinegar,cooking oil and chemical, emulsion, pesticide,daily chemical.Material contact surface manufactured with 304 or 316 stainless steel, uncontact surface manufactured with 304 stainless steel. This product filling can match protective cover, beautiful appearance,no pollution and in line with GMP standard request.
Automatic Gravity Type Liquid filling machine is mainly used for bottling of daily chemical, agricultural chemical and pharmaceutics industry.
Main Technical Data
Automatic Rotary Gravity Type Bottle filling machine Pictures
Automatic Rotary Gravity Type Bottle filling machine is suitable for below bottle samples
Liquid mosquito repellent incense filling machine, drinking water filling machinesoy sauce filling machine, vinegar filling machine, wine filling machine, liquor filling machine, alcohol filling machine, iodophor filling machine, Antifreeze filling machine, bath of glass filling machine, Bactericide, Insecticide, Herbicide, Liquid chemical fertilizer, Pesticides filling machine, farm chemical filling machine, emulsifiable concentrate filler, etc. Please tell us your products information, we will help clients to choose suitable machines.
Click here to view Automatic Inline Piston filling machine running video on YouTube
https://youtu.be/3fx8flvAxiE
Contact us to get more information and quotation
Automatic High Speed Rotary Gravity Flowing Type Bottle Liquid filling machine adopts rotating filling machine technology in our country. It i a high-tech filling equipment controlled by microcomputer PLC programmable, equip with photo electricity transduction and pneumatic action as a whole.Characteristic are: Fast filling speed, accurate measure,non-foam,non-drop.This machine with compact structure,simple transmission,convenient maintain,long service life,beautiful appearance.The product extensive used for non-aerated beverage,fruit juice,soy,vinegar,cooking oil and chemical, emulsion, pesticide,daily chemical.Material contact surface manufactured with 304 or 316 stainless steel, uncontact surface manufactured with 304 stainless steel. This product filling can match protective cover, beautiful appearance,no pollution and in line with GMP standard request.
Automatic Gravity Type Liquid filling machine is mainly used for bottling of daily chemical, agricultural chemical and pharmaceutics industry.
Main Technical Data
- filling nozzles: 8, 12, 24, 30pcs customized
- capacity: 6000-9000BPH (24pcs nozzles, 250ml filling volume)
- filling volume: 30-1000ml
- measurement precision: ±1%
- applicable bottle diameter: Φ30-100mm only need to change bottle fixed plates
- applicable bottle height: 60-300mm
- air pressure: 0.6-0.8Mpa
- total power: 3kw
- voltage: AC220V，50Hz
- net weight: 800kg
- dimension: 2000(L)×1300(W)×2100(H)mm
Automatic Rotary Gravity Type Bottle filling machine Pictures
Automatic Rotary Gravity Type Bottle filling machine is suitable for below bottle samples
Liquid mosquito repellent incense filling machine, drinking water filling machinesoy sauce filling machine, vinegar filling machine, wine filling machine, liquor filling machine, alcohol filling machine, iodophor filling machine, Antifreeze filling machine, bath of glass filling machine, Bactericide, Insecticide, Herbicide, Liquid chemical fertilizer, Pesticides filling machine, farm chemical filling machine, emulsifiable concentrate filler, etc. Please tell us your products information, we will help clients to choose suitable machines.
Click here to view Automatic Inline Piston filling machine running video on YouTube
https://youtu.be/3fx8flvAxiE
Contact us to get more information and quotation
- Email : sales@myhymachinery.com
- Skype: hymachinery01@hotmail.com
- Mobile: +8613776804621
