Automatic Weighing Filling Machine

  • MODEL: HYWF-30
  • Nozzles No.: 1-8pcs customized
BASIC INFO
Technical Description

Weighing type liquid filling machine is suitable for filling liquid from 5kg to 30kg, fully automatic complete bottle inlet, weight filling, bottle outlet and some other process, aims at oil realm such as SL, lubricating oil, edible oil etc and other realms like agrochemicals.
This machine is making up of the scale (with roller), chain-driven drum in and out structure, fast and slow filling (with dive function), material tank, weight control meter and PLC control unit. It has the dive function can eliminates the splash and foaming can.
This machine has PLC, touch screen control panel, convenient to adjust.
Diving method to fill and reduce foaming; it is suitable for various kinds of products
Easily dismantle, clean and maintain. The whole machine is safe, environmental, sanitary, adapting to various kinds of working place.
Weighing type liquid filling machine is mainly used for bottling of daily chemical, agricultural chemical, food and pharmaceutics industry.

Main Technical Data
  • Applicable bottle dia: Min 140×200×320mm, Max 260×290×500mm
  • Filling head outer dia: Ø40mm
  • Filling error: ±0.2%
  • Filling capacity: 5Kg-30Kg
  • Output: ≤600 Drum/hour
  • Air pressure: 0.6-0.8Mpa
  • Gas consumption: 150L/Min
  • Power supply: AC380V/50Hz
  • Total power: 2Kw
  • Weight: About 800Kg
  • Overall size: 2800×1400×2400mm

Automatic Inline Weighing Type Bottle Filling Machine Pictures






Automatic Inline Weighing Bottle Filling Machine is suitable for below bottle samples

pesticide drum filling machine, liquid fertilizer drum filling machine, automobile urea filling machine, antifreeze filling machine, motor oil filling machine, edible oil filling machine, paint filling machine, additive filling machine



Click here to view Automatic Inline Drum Filling Machine running video on YouTube

https://youtu.be/XDXJRlLWeb8
