Main technical data

• Applicable label length (mm): 15mm ~ 100mm

• Applicable label width (body paper width / mm): 15mm ~ 150mm

• Applicable product size (length × width × height / thickness): Length: 20mm ~ 200mm; Width: 20mm ~ 150mm; Thickness: 0.2mm ~ 120mm

• Applicable outer diameter of label roll (mm): φ340mm

• Applicable inner diameter of label roll (mm): φ76mm

• Labeling precision (mm): ± 0.5mm

• Label sending-out speed (m / min): 5m/min

• Labeling speed (pcs / min): 20 ~ 45pcs/min

• Voltage (V): 220V/50HZ, can be customized globally

• Power (W): 200W

• Air pressure (Mpa): 0.4 ~ 0.6Mpa

• Overall dimensions of the machine (mm) (L × W × H): about 850mm × 410mm × 720mm

• Weight (kg): about 48kg


Application



• Applicable labels: self-adhesive label, self-adhesive film, electronic supervision code, bar code, etc.
• Applicable products: products require labeling on flat surface, arc surface, circumferential surface, concave surface, convex surface and other type surfaces.
• Application industries: widely used in cosmetics, food, toy, daily chemical, electronics, pharmaceutical and other industries.
• Application examples: labeling on shampoo flat bottles, packaging boxes, bottle caps, plastic shell, flat boxes, book surface, cream lid top, square bottles labeling machine applicator etc.
